E2-05XX-MOD connection cable with RS-485 Modbus interface ROTRONIC

Description

E2-05XX-MOD is a female connector (black) for HC2 temperature sensors (8 wires with tin ends). It powers the HC2 and allows connection to an RS-485 or Modbus network, depending on the communication protocol used. It is 5 m long.

Main features E2-05XX-MOD

• connection of HC2 sensors in RS-485 or Modbus network
• switching between Modbus and RS-485 protocol possible in HW4 software (newer version is HW5)
• adapter power supply: 5.0…28 V DC
• Sensor power supply: 3.3 V DC
• Extension range: -40 … +70 °C
• Connector operating range: -50 … +100 °C
• 8 wired
• Connector length: 82 mm
• female connector
• material: PUR, polycarbonate
• Length: 5 m

It is an accessory for relative humidity and temperature sensors, such as the most commonly used sensor, the standard Rotronic HC2A-S. It measures relative humidity and temperature and calculates the dew point/freezing point with extreme accuracy. Connection cable up to 5 m passive or 100 m active.

You may also be interested in HC2 ROTRONIC cables and extension leads for connecting sensors to meters, data loggers and handheld portable meters. HC2 cables and extensions are up to 10 metres long. For even longer distances, you can use the AC3003 signal booster for distances up to 100 metres.

For more information and to help you choose the right cable or extension cable, please refer to the documentation under ”Catalogue cables and extension cables_ROTRONIC”.

Other accessories in addition to E2-05XX-MOD

• HC2 ROTRONIC cables and extensions
• Filters for HC2A relative humidity sensors
• Filters for HC2 relative humidity sensors
• AC5005 sensor mounting flange
• E2-01A extension cable
• E2-02A extension cable
• E2-05A extension cable
• ER-15 sensor calibration device
• EA Relative Humidity standards

Recommendation: for longer distances, up to 100 m, an extension cable with built-in AC3003 amplifier should be used.

Other designations: E2 05XX-MOD, E2_05XX MOD, E205XXMOD
